HSW15TEX Single Kit

Hydraulic flange spreader (HSW15TEX Single Kit) with safety loop, step blocks and safety block
Hydraulic flange spreader (HSW15TEX Single Kit) with transport case, safety strap, step blocks and safety block
Hydraulic flange spreader (HSW15TEX Single Kit) with safety loop, step blocks and safety block in metal transport case
Hydraulic flange spreader (HSW15TEX) in between orange pipes with safety loop and safety block
Hydraulic flange spreader (HSW15TEX) in between orange pipes with red Hydraulic hose
Hydraulic flange spreader (HSW15TEX) in between orange pipes

HSW15TEX Single Kit

Hydraulic Flange Spreader ATEX 15,5 ton

1 x HSW15TEX Hydraulic Flange Spreader
with Hydraulic Cylinder 700bar
1 x Safety Block & Lanyard
1 x Pair of Stepped Blocks
1 x Carry Case
Tool Only Weight (KG) 7,0
Gross Kit Weight (KG) 12,2


This device features the following ATEX classification
II 2G ck IIB T6 / II 2D ck T85°C.



Categories: ,

Description

Hydraulic Flange Spreader ATEX 15.5 ton

The HSW15TEX hydraulic flange spreader from MATCH is a professional service tool with a spreading force of 15.5 tonnes (155 kN). Designed for safe separation of flanges in industrial installations. Thanks to its compact design and minimal insertion width of only 6 mm, the tool is ideal for use in confined spaces, e.g. when replacing gaskets or valves.

The HSW15TEX model is powered by an external hydraulic pump.

The HSW15TEX Single Kit and HSW15TEX Twin Kit do not include a hydraulic hand pump or hoses. MATCH recommends using the HP350AEX pump kit for the single version and the HP350BEX for the double version.

Our company, MATCH, has designed the HSW15TEX spreader for use in harsh conditions, including explosion hazard zones. The ATEX certificate enables users to safely operate the device in zones 1 and 2 explosive atmospheres (excluding the PU case). Experts particularly recommend the tool for use in the petrochemical, refining, energy, maritime, and offshore industries.

MATCH HSW15TEX is a reliable and proven solution for professionals who care about safety, precision and compliance with ATEX standards. Check out our offer on DirectIndustry! All our products are listed there. Compare MATCH products with other competitive products and you will see that MATCH is the best choice!

*Please note the differences between ATEX-certified kits and components and those that are not.



Tool Capabilities

SPREADING FORCE
with 700bar hydraulic pressure applied:
▪ 15.5T (155kN)

SPREADING DISTANCE
▪ 6.0mm - 31.0mm
st using only 1st step
▪ 6.0mm - 62.0mm
using 4 steps (without stepped blocks)
▪ 31.0mm - 81.0mm
using optional stepped blocks kit

TOOL WEIGHT: 7.0kg

Technical Data Sheets

Operating manual only upon request

TDS_HSW15TEX_Single-Kit_EN
